Home > LED Flex > One Color >   SMD 5050 10mm static color LED strip 30LEDs/M DC12V/24V

SMD 5050 10mm static color LED strip 30LEDs/M DC12V/24V

Description

- This flexible LED strip with 30pcs SMD 5050 LEDs per meter
- FPC in white color with 10mm Width
- All soldering Pads are very large, allow you to cut and reconnect very easy
- 2pin bare wires at both ends for powering
- 3M tape attached on backside of FPC, 5 meters in a reel
- A variety of colors are available



Share to

Facebook Twitter g+

Specification

Product Parameter

    PN
    S010030CB1LZ
 S010030CC1LZ
    Voltage
    DC12V
 DC24V
    LED Type
    SMD 5050
 SMD 5050
    LED Quantity     30LEDs/m
 30LEDs/m
    CCT
    3000K/4000K/6500K
 3000K/4000K/6500K
    Dimension
    5000*10mm
 5000*10mm
    Lumens/m
    682lm
 682lm
    SDCM
    <5
<5
    PCB Color     White  White
    Power
    7.2W/m
 7.2W/m
    CRI
    80RA  80RA
    O.T     -25℃ ~ 60℃   -25℃ ~ 60℃



Dimension (unit:mm)

IP Rate
